Winding type

Star

Hall effect angle

120° （electrical angle）

Shaft run out

0.025mm

Radial play

0.06mm@450g

End play

0.08mm@450g

Max.radial force

200N@10mm from   the flange

Max.axial force

60N

Insulation class

Class B

Dielectric Strength

500VDC for one minute

Insulation resistance

100MΩMin.500VDC

Number of   phase

3

Number of   pole

4 (8)

Rated   Voltage

V

24v   (Option for 12v up to 48vdc)

No   load Speed

rpm

4000

4000

4000

3000

3000

2500

Rated   Torque

Nm

0.4

0.5

0.8

1.0

1.2

1.5

Rated   Speed

rpm

3000

3000

3000

2000

2000

1500

Rated   Current

A

7

8

14

12

14

13

Rated   Power

W

126

157

252

210

250

236

Weight

Kg

1.1

1.2

1.5

1.7

2.0

2.3

Length

mm

55

60

70

80

90

100
